Aprilaire 1150 Steam Humidifier

Search Results for

    Select a diagram to view its parts

    Parts

    Diagram

    Parts
    1
    2
    3
    4
    5
    6
    7
    8
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    24
    25

    Parts

    1. 1
      Steam Chamber
      Steam Chamber
      SKU: 4560
      $950.30
    2. 2
      Quick Release Handle
      $312.05
    3. 3
      Cover Shroud
      Cover Shroud
      SKU: 4564
      $803.91
    4. 4
      Terminal Block
      $112.01
    5. 5
      Safety Relay AC
      $228.33
    6. 6
      Control Relay DC
      $125.75
    7. 7
      Single Fuse Holder 30 Amp
      $93.32
    8. 8
      Fuse 25 Amp
      Fuse 25 Amp
      SKU: 4569
      $92.23
    9. 10
      Terminal 20 Amp
      $103.90
    10. 11
      Transformer
      Transformer
      SKU: 4572
      $150.31
    11. 12
      Overlay & Switch
      $214.48
    12. 13
      Circuit Board
      Circuit Board
      SKU: 4574
      $725.02
    13. 14
      PC Board Clip St&off
      $113.22
    14. 15
      Heater
      Heater
      SKU: 4576
      $328.67
    15. 16
      Auto Reset High Limit
      $173.31
    16. 17
      Probe Housing
      Probe Housing
      SKU: 4578
      $134.49
    17. 18
      Gasket
      Gasket
      SKU: 4579
      $94.53
    18. 19
      Water Level Probe
      $204.93
    19. 20
      Plug Vert Wire Assembly Probe
      $225.63
    20. 21
      Gasket
      Gasket
      SKU: 4582
      $145.02
    21. 22
      Valve
      Valve
      SKU: 4584
      $209.76
    22. 23
      Drain Valve
      Drain Valve
      SKU: 4585
      $688.62
    23. 24
      Drain Assembly
      $1,012.12
    24. 25
      Over Temp Limit Non Resetable
      $242.36

    Parts Not In Diagram

    1. Not Shown
      Electrical Wire Harness
      $378.47
    2. Not Shown
      Steam Hose
      Steam Hose
      SKU: 4588
      $744.11
    3. Not Shown
      Tube Weld
      Tube Weld
      SKU: 4589
      $418.08
    4. Not Shown
      Duct Plate
      Duct Plate
      SKU: 4591
      $11.10
    5. Not Shown
      Airflow Switch
      $176.01
    6. Not Shown
      Automatic Steam Humidifier Control
      $609.96
    7. Not Shown
      Hanging Bracket
      $273.13
    8. Not Shown
      Duct Mount High Limit Humidistat
      Duct Mount High Limit Humidistat
      SKU: BARHC201
      (Substitute part number)
      $241.80
